Reduced Shank Standard Radius Milling Cutter End Mill , High Performance ,HRC55

Product Details:

Place of Origin:	China
Brand Name:	INMIND
Certification:	SGS Factory Certificater
Model Number:	Corner Radius Standard Length Type 1mm to 20mm

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs per specification wthin 12mm
Price:	Negotiable
Packaging Details:	1 piece packing
Delivery Time:	For Samples: 3-5 days For Batch:10 to 15 days.
Payment Terms:	T/T 100% Advinced,Paypal,Western Union
Supply Ability:	50000pcs/month

Contact Now

Detailed Product Description

Features:	High Speed\|Micro	Application:	Stainless Steel\|Milling\|Rouhing To Finishing\|Slotting
Coating:	Tialn Coated	HRC:	HRC55
Material:	Solid Carbide\|Carbide	Product Name:	Corner Radius End Mill
Type:	Standard	Helix Angle:	30
Processing Mode:	CNC
Highlight:	corner radius end mill cutter

Reduced Shank Standard Radius Milling Cutter End Mill , High Performance

Quick Detail:

0.5-0.6um Ultra-Fine grain size solid carbide rod

TIALN Coating (Black),TiSiAlN(Copper)

Made by 5 AXIS CNC grinder

Checked by Zoller Inspection Equipment

Workpiece upto HRC55

1 piece packing.

Standard Length Type

Description:

Ultra-Fine Grain Szie 0.5-0.6um, Wc carbide rod with high tenacity,with high quality TiAlN coating,getting long

tool life,from roughing to finishing processing,reduce time of changing cutters,improving efficency of machine,

saving time of making moulds.

Suggest to process iron and steel upto HRC55,Middle-High speed.

Carbide Rod:Wc:88%,Co:12%,TRS:4000N/mm2, Grain Size:0.5-0.6um

Applications:

Fit for milling quenching and tempered steel.stainless steel.nickel alloy and Titanium alloy.

Cast iron,enhanced composited material with fiberglass,Also fit for milling copper.

Specifications:

Reduced Shank Standard Radius Milling Cutter End Mill , High Performance ,HRC55 0

Order No	Cutting Diameter	Flute length	Shank Diameter	R Corner	A.O.L
Order No	d	l	D	R	L
1×3×4D×R0.2×50L×2F	1	3	4	R0.2	50
1×3×4D×R0.3×50L×2F	1	3	4	R0.3	50
1.5×3×4D×R0.2×50L×2F	1.5	4	4	R0.2	50
1.5×3×4D×R0.3×50L×2F	1.5	4	4	R0.3	50
2×6×4D×R0.2×50L×4F	2	6	4	R0.2	50
2×6×4D×R0.3×50L×4F	2	6	4	R0.3	50
2×6×4D×R0.5×50L×4F	2	6	4	R0.5	50
2.5×8×4D×R0.2×50L×4F	2.5	6	4	R0.2	50
2.5×8×4D×R0.5×50L×4F	2.5	6	4	R0.5	50
3×8×3D×R0.3×50L×4F	3	8	3	R0.3	50
3×8×3D×R0.5×50L×4F	3	8	3	R0.5	50
3×8×4D×R0.3×50L×4F	3	8	4	R0.3	50
3×8×4D×R0.5×50L×4F	3	8	4	R0.5	50
4×10×4D×R0.5×50L×4F	4	10	4	R0.5	50
4×10×4D×R1.0×50L×4F	4	10	4	R1.0	50
4×10×6D×R0.5×50L×4F	4	10	6	R0.5	50
4×10×6D×R1.0×50L×4F	4	10	6	R1.0	50
5×13×6D×R0.5×50L×4F	5	13	6	R0.5	50
5×13×6D×R1.0×50L×4F	5	13	6	R1.0	50
6×15×6D×R0.5×50L×4F	6	15	6	R0.5	50
6×15×6D×R1.0×50L×4F	6	15	6	R1.0	50
8×20×8D×R0.5×60L×4F	8	20	8	R0.5	60
8×20×8D×R1.0×60L×4F	8	20	8	R1.0	60
8×20×8D×R1.5×60L×4F	8	20	8	R1.5	60
10×25×10D×R0.5×75L×4F	10	25	10	R0.5	75
10×25×10D×R1.0×75L×4F	10	25	10	R1.0	75
10×25×10D×R1.5×75L×4F	10	25	10	R1.5	75
10×25×10D×R2.0×75L×4F	10	25	10	R2.0	75
12×30×13D×R0.5×75L×4F	12	30	12	R0.5	75
12×30×13D×R1.0×75L×4F	12	30	12	R1.0	75
12×30×13D×R1.5×75L×4F	12	30	12	R1.5	75
12×30×13D×R2.0×75L×4F	12	30	12	R2.0	75

Competitive Advantage:

Good Quality,Competitive price.Help the agent to get the more large market

We promise to reply your mail within 12 hours

Reduced Shank Standard Radius Milling Cutter End Mill , High Performance ,HRC55 1

Reduced Shank Standard Radius Milling Cutter End Mill , High Performance ,HRC55 5
