Chamfer Long Reach Corner Radius End Mill 4 Flute Solid Carbide Cutting Tool , HRC50

Product Details:

Place of Origin:	China
Brand Name:	INMIND
Certification:	SGS Factory Certificater
Model Number:	Corner Radius Long Shank Type 1mm to 20mm

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs per specification wthin 12mm
Price:	Negotiable
Packaging Details:	1 piece packing
Delivery Time:	For Samples: 3-5 days For Batch:10 to 15 days.
Payment Terms:	T/T 100% Advinced,Paypal,Western Union
Supply Ability:	50000pcs/month

Contact Now

Detailed Product Description

Features:	Micro\|Middle Speed	Application:	Stainless Steel\|Milling\|Rouhing To Finishing\|Slotting
Coating:	Tialn Coated	HRC:	HRC50
Material:	Solid Carbide\|Carbide	Product Name:	Corner Radius End Mill
Type:	Long Shank	Helix Angle:	35
Processing Mode:	CNC
Highlight:	corner radius end mill cutter

Chamfer Long Reach Corner Radius End Mill 4 Flute Solid Carbide Cutting Tool , HRC50

Quick Detail:

0.6-0.8um Mirco grain size solid carbide rod

TIALN Coating ,high Aluminium (Black),Middle Aluminium(Copper)

Made by 5 AXIS CNC grinder

Checked by Zoller Inspection Equipment

Workpiece upto HRC50

1 piece packing.

Corner Radius Long Shank Type

Description:

Micro Grain Szie 0.6-0.8um, Wc carbide rod with high tenacity,with high quality TiAlN coating,getting long tool life,from roughing to finishing processing,reduce time of changing cutters,improving efficency of machine,saving time of making moulds.Suggest to process iron and steel upto HRC50,Middle-low speed.

Carbide Rod:Wc:90%,Co:10%,TRS:3800N/mm2, Grain Size:0.6-0.8um

Applications:

Fit for milling quenching and tempered steel.stainless steel.nickel alloy and Titanium alloy,Cast iron,enhanced composited material with fiberglass,Also fit for milling copper.

Specifications:

Chamfer Long Reach Corner Radius End Mill 4 Flute Solid Carbide Cutting Tool , HRC50 0

Order No	Cutting Diameter	Flute length	Shank Diameter	R Corner	A.O.L
Order No	d	l	D	R	L
3×R0.5×8×3D×75L×4F	3	8	3	R0.5	75
3×R0.5×8×3D×100L×4F	3	8	3	R0.5	100
3×R0.5×8×4D×75L×4F	3	8	4	R0.5	75
3×R0.5×8×4D×100L×4F	3	8	4	R0.5	100
4×R0.5×11×4D×100L×4F	4	11	4	R0.5	100
6×R0.5×15×6D×100L×4F	6	15	6	R0.5	100
8×R0.5×20×8D×100L×4F	8	20	8	R0.5	100
10×R0.5×25×10D×100L×4F	10	25	10	R0.5	100
10×R1.0×25×10D×100L×4F	10	25	10	R1.0	100
10×R1.5×25×10D×100L×4F	10	25	10	R1.5	100
10×R2.0×25×10D×100L×4F	10	25	10	R2.0	100
12×R0.5×30×12D×100L×4F	12	30	12	R0.5	100
12×R1.0×30×12D×100L×4F	12	30	12	R1.0	100
12×R1.5×30×12D×100L×4F	12	30	12	R1.5	100
12×R2.0×30×12D×100L×4F	12	30	12	R2.0	100
8×R0.5×25×8D×150L×4F	8	25	8	R0.5	150
10×R0.5×30×10D×150L×4F	10	30	10	R0.5	150
10×R1.0×30×10D×150L×4F	10	30	10	R1.0	150
10×R1.5×30×10D×150L×4F	10	30	10	R1.5	150
10×R2.0×30×10D×150L×4F	10	30	10	R2.0	150
12×R0.5×35×12D×150L×4F	12	35	12	R0.5	150
12×R1.0×35×12D×150L×4F	12	35	12	R1.0	150
12×R1.5×35×12D×150L×4F	12	35	12	R1.5	150
12×R2.0×35×12D×150L×4F	12	35	12	R2.0	150

Competitive Advantage:

Good Quality,Competitive price.Help the agent to get the more large market

Chamfer Long Reach Corner Radius End Mill 4 Flute Solid Carbide Cutting Tool , HRC50 1

Chamfer Long Reach Corner Radius End Mill 4 Flute Solid Carbide Cutting Tool , HRC50 2
